Model | IB19 | IB26 | IB29 | IB39 |
Operating Environment | Indoor | Indoor | Indoor | Indoor |
Pixel Pitch | 1.953mm | 2.604mm | 2.976mm | 3.906mm |
LED Type | SMD1515 | SMD1515 | SMD2020 | SMD2020 |
Module Size | 250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm |
Module Resolution | 128dots*128dots | 96dots*96dots | 84dots*84dots | 64dots*64dots |
Panel Size | 1000mm*250mm or | 1000mm*250mm or | 1000mm*250mm or | 1000mm*250mm or |
Panel Resolution | 512*128dots or | 384*96dots or | 336*84dots or | 256*64dots or |
Panel Weight | 5.5kg or 4.0kg | 5.5kg or 4.0kg | 5.5kg or 4.0kg | 5.5kg or 4.0kg |
Pixel Density | 262,144dots/m² | 147,456dots/m² | 112,896dots/m² | 65,536dots/m² |
Scan Mode | 1/32 | 1/32 | 1/28 | 1/16 |
Brightness | 1,000nits | 1,000nits | 1,000nits | 1,000nits |
Refresh Rate | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz |
Gray Scale | 16bit | 16bit | 16bit | 16bit |
Contrast Rate | 4000:1 | 4000:1 | 4000:1 | 4000:1 |
Max. Power Consumption | 680W/m² | 680W/m² | 680W/m² | 680W/m² |
Ave. Power Consumption | 230W/m² | 230W/m² | 230W/m² | 230W/m² |
Power Input | AC90V-AC240V; 50Hz/60Hz | AC90V-AC240V; 50Hz/60Hz | AC90V-AC240V; 50Hz/60Hz | AC90V-AC240V; 50Hz/60Hz |
VIewing Angle | H:160°/V:160° | H:160°/V:160° | H:160°/V:160° | H:160°/V:160° |
Operating Temperature | ﹣20℃～65℃ | ﹣20℃～65℃ | ﹣20℃～65℃ | ﹣20℃～65℃ |
Operating Humidity | 10%～90% | 10%～90% | 10%～90% | 10%～90% |
Protection Grade | IP31 | IP31 | IP31 | IP31 |
Panel Material | Die-cast Aluminium | Die-cast Aluminium | Die-cast Aluminium | Die-cast Aluminium |
Operating Access | Front | Front | Front | Front |
